Description

Technical Parameters

Parameters

● Product model: FT8K1200DZ-01

● Lamp type: high-pressure mercury lamp

● Lamp power: 8KW

● Lamp quantity: 1pc

● Lamp wavelength: 200nm-450nm (peak value: 365nm)

● Cooling fan: 1set, 750W

● Total power: 8.8KW

● Input voltage: three-phase 380V 50-60Hz

● Lampshade size: L1360mm × W200mm × H250mm

● Controller size: L600mm × W350mm × H1230mm

Core Advantages

Precise adaptation

The power, lamp tube configuration and size can all be customized from laboratory-level to industrial-level requirements, perfectly matching production scenarios.

High-efficiency curing

The optimized optical system design ensures concentrated UV energy output,

significantly improving the curing efficiency and consistency.

Intelligent control

The optional advanced control system enables digital management of curing parameters, supporting process data traceability and optimization.

Modular design

Supports expansion of cooling systems, conveying devices and nitrogen protection modules to meet high-end process requirements.

Long-term stability

The multiple protection mechanisms ensure continuous equipment operation, significantly reducing maintenance cost and downtime risk.

Typical Applications

Printing and packaging

Efficient curing of UV inks, laminated films and special coatings

Electronic manufacturing

PCB encapsulation, component fixation and optical adhesive curing

Automotive field

Lamp bonding, interior component UV coating treatment

Industrial painting

Surface curing of metals, plastics and composite materials

Technical Characteristics

Power range

Covers basic curing to high strength industrial requirements

Irradiation intensity

Adjustable design to meet different material requirements

Cooling scheme

Air cooling or water cooling can be chosen to ensure long-term stable operation

Control mode

Supports manual / automatic/remote monitoring multi-mode operation

Service Support

We offer a free installation scheme, a team consisting of professional business managers and multiple technical engineers will provide you with many to one exclusive service, covering the entire process from requirement analysis to scheme confirmation, system design, production manufacturing, shipment quality inspection, installation guidance. Each stage is fully monitored by a professional team to ensure that the system perfectly matches your production needs. At the same time, we provide rapid technical response and lifetime maintenance support to free you from worries.

This system focuses on the flexible configuration and industrial-grade reliability as its core value, helping enterprises achieve intelligent and green production upgrades.

Company Introduction

Ergu Optoelectronics Profile

Ergu Optoelectronics Technology Co., Limited is a comprehensive UV optical manufacturer which was founded in 2011. The company is a national technology enterprise integrating R&D, production, sales and services as one, has been dedicated to researching and developing a variety of UV lamps, UV curing equipment, UV reaction systems and UV treating systems. The company has numerous practical and technological inventions under his banner, and all necessary product certifications are ready. The products are widely applied in the fields of electronics, LCD, semiconductor, coating, painting, printing, chemical industry(pharmacy, biology, lithium battery), water-treating, trenchless pipeline repairing, etc.

Professional team

The senior R&D team has rich experience and can design customized solutions for each enterprise, precisely matching the production requirements.

Patent certificate

There are nearly 30 patents and the company has obtained certifications such as ISO9001 and CE, both technology and quality standards have been met.
